The B200 series delivers powerful AIS Class B performance with exceptional reliability, safety and endurance. Even in the harshest of marine conditions, you are visible and connected.
The B200 series combines certified AIS Class B performance with intelligent power management and plug-and-play connectivity. With its internal battery backup and ultra-low power consumption, it continues transmitting vital AIS data for up to 120 hours, even when vessel power is lost, to give peace of mind in all conditions.
When you’re navigating busy waterways or offshore routes, the B200 series is your dependable AIS partner.
AIS SOLUTIONS
Built to withstand the harshest environments, the B200 series is IPX7-rated and protected against vibration, temperature extremes, and power surges. Integrated WiFi, Bluetooth, and NMEA 0183/2000 ensure simple, seamless integration with your vessel systems.
The B200 Series uses 5W SOTDMA transmission technology for faster and more frequent updates and higher priority in busy areas. Combined with RF screening and surge protection, it ensures reliable, interference-free performance in any situation.
Automatic switch to internal battery on loss of primary vessel power, with up to 120 hours of operation.
Faster update rate and higher transmission priority for enhanced visibility and safety.
Integrated WiFi and Bluetooth plus NMEA 0183 and 2000 for simple, flexible integration.
Advanced RF screening protects against interference from other electronics on board.
Safeguards internal systems from voltage spikes and electrical noise.
Designed for continuous operation with low power draw.
Offshore sailing, Commercial workboat, Offshore sport fishing, Expedition and adventure cruising, Recreational power and sail
Size (w x h x d) – 170 x 140 x 69mm
Weight – 695g
Operating temperature – -25°C to +55°C
Storage temperature – -25°C to +70°C
Ingress protection – IPx6 and IPx7
AIS standards – IEC 62287-2 Ed. 2. ITU-R M.1371.5
Product safety standards – EN60950-1 2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013 EN62311:2008
Environmental standards – IEC 60945 Ed. 4
Serial data interface standards – IEC 61162-1 Ed 5.0. IEC 61162-2 Ed 1.0
NMEA 2000 – NMEA 2000 Ed 3.101
GNSS performance standards – IEC 61108-1 Ed 2.0. IEC 61108-02 Ed 1.0
Supply voltage – 12V or 24V DC
Supply voltage range – 9.6V – 31.2V DC
Average current (at 12V) – 240mA (1.6A when battery charging)
Peak current – 3.85A
Average power consumption (at 12V) – 2.9W (19.2W when battery charging)
Galvanic isolation – NMEA 0183 inputs only, NMEA 2000, VHF antenna port
Battery Capacity – 4600mAh
Battery Type – 3.7V Li-Ion rechargeable
Battery life (default operating conditions) – 48 hours
Systems supported – GPS, GLONASS, BeiDou, Galileo (two of any combination, three including GPS, Galileo)
Channels – 72
Internal/external antenna – External only
Time to first fix from cold start – 26s
VHF antenna – SO-239
GNSS – TNC
Power – 2 way circular multipole
NMEA 0183/silent mode – 12 way circular multipole
NMEA 2000 – 5 way Micro-C connector
USB – USB Micro-B
VDL access scheme – SOTDMA
Operating frequency – 156.025MHz – 162.025MHz
Channel bandwidth – 25kHz
Receivers/transmitters – 2 x receivers, 1 x transmitter
AIS receiver sensitivity (20% PER) – -111dBm
AIS transmitter power – 5W (+37dBm)
NMEA 0183 – 2 x bi-directional ports
NMEA 2000 – NMEA 2000 Ed 3.101, LEN=1
USB – PC virtual com port for NMEA 0183 data
Wi-Fi – IEEE 802.11 (a/b/g), client and access point mode supported (2 connections in access point mode)
Bluetooth – BT Classic 4.0, 7 concurrent connections
Buttons – Integrated silent mode
Indicators – Power, transmit timeout, error, silent mode
Size – 85 x 70mm
Weight – 470g
Ingress Protection – IPx6 and IPx7
Mounting – 1 inch 14 TPI pole mount required
GNSS systems supported – GPS, GLONASS, Galileo, BeiDou
All em-trak products are supplied with a comprehensive three-year global warranty for complete peace of mind.
Customers may return unused products for a full refund within 48 hours of receipt, provided the product and packaging are complete, undamaged, and notification is received in writing within this timeframe. Returns cannot be accepted if the product has been used, damaged, or if any packaging components are missing.
In the unlikely event of a fault, em-trak’s Customer Support team is available 24/7 at support@em-trak.com. Our specialists will assist in diagnosing the issue and, where appropriate, arrange repair or replacement under warranty. Please note that the warranty does not cover products that have been misused, damaged through improper handling, or tampered with.
